Electrofusion End Cap is a fitting designed by electrofusion welding method to close the pipe ends in HDPE (High Density Polyethylene) pipelines and to terminate the line safely. It is used for temporary or permanent closure of the open ends of the pipeline.
Electrofusion End Cap – Leak-Free Termination Solution for HDPE Pipe Systems
Product Description:
The heater elements integrated on the cap, when connected to the electrofusion welding unit, melt the HDPE surface, creating a homogeneous, strong and sealed weld joint. Special production is available in different diameters and according to project requirements. EF END CAP
Areas of Use:
Water and drinking water infrastructure systems
Natural gas and LPG pipelines
Waste water and sewage installations
Temporary shutdown for testing and maintenance work
New lines and network terminations
Advantages:
Fast and safe assembly with electrofusion technology
Leak-proof, durable and long-lasting connection
High resistance to corrosion, chemical and external factors
Easy disassembly and reassembly (some types)
Project-specific diameter and thickness options
Low labor cost and fast implementation
Technical Specifications:
Material: HDPE (PE100)
Connection Method: Electrofusion welding
Pressure Class: PN10 / PN16
Conformity ISO 4427, EN 12201, EN 1555
Sıra | Ürün Kodu | Ürün Adı | D (mm) | d (mm) | L (mm) | Le1 (mm) | Ağırlık (kg) |
---|---|---|---|---|---|---|---|
SEQ | Product Code | Product Name | D (mm) | d (mm) | L (mm) | Le1 (mm) | Weight (kg) |
1 | 973355100020 | 20 EF Kep | 36 | 20 | 85 | 80 | 0,06 |
2 | 973355100140 | 140 EF Kep | 184 | 140 | 110.5 | 91.8 | 1.3 |
3 | 973355100160 | 160 EF Kep | 202.8 | 160 | 118.4 | 95.9 | 1.74 |
4 | 973355100180 | 180 EF Kep | 230.6 | 180 | 150 | 103 | 2.8 |
5 | 973355100200 | 200 EF Kep | 256.1 | 200 | 143 | 107.5 | 3.1 |
6 | 973355100225 | 225 EF Kep | 285.2 | 225 | 148.5 | 113 | 4.16 |
